Stainless steel construction
Pot botton round design, easy for cleaning
Choose hand wheel type or electric drive type tilting pan asper the request
Hand wheel use worm geared drive tilting pan
Electri use imported lifting pan tilting pan
The pot body protection is not in place
The pot bottom temperature use temperature sensor control
Equipped with stainless steel adjustable feet, it is convenience to install on vessel | DQG-9 | DQG-10 | DQG-12 | DQG-14 | DQG-10D | DQG-12D | DQG-12D | |
|---|---|---|---|---|---|---|---|
| Capacity(L) | 40 | 60 | 80 | 100 | 60 | 80 | 100 |
| Voltage | 380/415V-3PH-50Hz | 440/480V-3PH-60Hz | |||||
| Power (Kw) | 9 |
10.8 | 12.6 | 14.8 | 10.8 | 12.6 | 14.8 |
| Size (mm) | 700 ×700 × 850 | 850 × 750 × 850 | 1000 × 700× 850 | 1000 × 850 × 850 | 850× 700 × 850 | 1000 × 700 × 850 | 1000 × 850 × 850 |
| Weight (kg) | 120 |
140 | 150 | 160 | 160 | 170 | 165 |
| Note | / | / | / | / | Motor-drive | Motor-drive | Motor-drive |
